Ballast CWA 60Hz Multi Volt 120-277v

Parameter	120V	208V	240V	277V
Input Volts	120	208	240	277
Circuit Type	CWA	CWA	CWA	CWA
Line Volts Regulation	±10%	±10%	±10%	±10%
Lamp Watts Regulation	±10%	±10%	±10%	±10%
Line Current – Operating (A)	9.00	5.20	4.50	3.90
Line Current – Open Circuit (A)	6.00	3.50	3.00	2.60
Line Current – Starting (A)	6.00	3.50	3.00	2.60
Recommended Fuse (A)	25	15	12	10
Insulation Class	H	H	H	H
Coil Temperature Code	C	C	B	B
Benchtop Coil Rise	86.9	68.2	74.1	74.2
Power Factor (Min)	90%	90%	90%	90%
Input Watts	1080W	1080W	1080W	1080W
Efficiency	–	–	–	–
Current Crest Factor	1.60	1.60	1.60	1.60
Nominal Open Circuit Factor	420	420	420	420
Input Voltage at Lamp Dropout	70	125	140	160
Min Ambient Starting Temp	-20°F / -30°C	-20°F / -30°C	-20°F / -30°C	-20°F / -30°C
